Description
COMMERCIAL DATA (NAK-6/PT) |
Weight | 100 g |
Dimensions | 93x83x40 mm |
Bulk package | 48 [pcs.] |
TECHNICAL DATA (NAK-6/PT) |
Type | NAK-6/PT |
Input frequency range | 5 ÷ 862 MHz |
TV output frequency range | 5 ÷ 70, 120 ÷ 862 MHz |
R output frequency range | 88 ÷ 108 MHz |
Coupling attenuation IN-TV | 5,1 ÷ 6,7 dB |
Coupling attenuation IN-R | 6,1 ÷ 7,9 dB |
Cross-talk attenuation TV-R | ≥ 10,7 dB |
R output connector | IEC female |
TV output connector | IEC male |
Wave impendance IN/OUT | 75 Ω / 75 Ω |
Case | Flush mounted |
Colour | White |
Reference standards | PN-EN 50083 PN-EN 60728-11 |
informations |
Documentation: • technical data • inner diagram • dimensions • apperance • user manual • certificate (PL) Diagrams and drawings: • cable assembly • connection • mechanism appearance Characteristics: • attenuation IN-R • attenuation IN-TV Family product: • NAR-1/PT • NAR-1/NT • NAK-6/PT • NAK-6/NT • NAP-9/PT • NAP-9/NT |
